Ground-recessed luminaires Lutera 100 Lens Black ET 14W 800lm 0 rotationally sym. wide (RB) IP68 IK10 3 SDCM

LEDGround-recessed spotlight for accent lighting, walkable and driveable. for ground recessing. Pivotable LED system + / - 10 °. With rotationally symmetric wide light distribution. beam angle 50°. Luminaire luminous flux and light color fixed. LED system configured with 6 LEDs. Luminaire luminous flux 800 lm, connected load 14 W, maximum luminous efficiency of luminaire 57 lm/W. Light colour green. Colour locus tolerance (initial MacAdam) ≤ 3 SDCM. Further LED light colours available on request. Mean rated service life L80(tq 25 °C) = 50,000 h. Spotlight housing and cover ring of die-cast aluminium, colour deep black, similar to RAL 9005, powder-coated. (RAL 9005). Cover of 15 mm thick, hardened glass, clear. Static load to 1500 kg. Can be rolled over to 2500 kg. Cover ring is permanently fixed with locking screws and threaded inserts of stainless steel. Ground recessing bowl of weather-resistant PVC tube. With luminaire mounting ring of glass-fibre reinforced PA6. Safety class (EN 61140): II, protection rating (DIN EN 60529): IP68, impact resistance level in accordance with IEC 62262: IK10. Weight: 1,3 kg. Wired ready for connection. With connection cable fed outwards, 2 x 1.5 mm2, sealed with appropriate protection rating. Inner connection compartment sealed with epoxy resin. The luminaire is suitable for operation on a 230V direct voltage supply grid (DC). With electronic control gear unit, switchable Surge voltage resistance Differential Mode / Common Mode: / . The luminaire complies with the fundamental requirements of applicable EU regulations and product safety legislation and bears the CE symbol.
