Fuse-link NH000 gG 690VAC 40A isolated tags Double indicator
En stock: Non
Stock fournisseur: Non
Quantité minimale de commande: 1
Prix (hors TVA):
Prix sur demande
EAN: 4086500088478
MPN: P229714
Colis: 3
Délai de livraison estimé à notre entrepôt (environ):
Sur demande
Technical Information
| État de l’article | Nouveau |
| Nom du fabricant | Fuse-link NH000 gG 690VAC 40A isolated tags Double indicator |
| Marque | Mersen |
| Catégories |
Fuses
|
| Pays d’origine | HU |
| Code du système harmonisé | 8536 1050 00 |
| Type de tension | AC/DC |
| Courant nominal | 40 A |
| Type d'indicateur d'état du fusible | Indicateur d'état des fusibles combinés |
| Tension nominale AC | 690 V |
| Tension nominale DC | 250 V |
| Perte de puissance au courant nominal | 3.7 W |
| Cosses métalliques isolées (IMGL) | Yes |
| Type de fusible selon IEC 60269 | NH000 |
Détails d’emballage
| Niveau d’emballage 1 | 4086500088479 |
Téléchargements
Description
The NH system is classified among plug-in fuse systems and is composed of:* fuse-base (possibly including terminal covers and phase barriers)* fuse-link with blade contact* fuse-link replacement device (LV HRC fuse puller)Since the design of this system cannot guarantee non-interchangeability of rated current it must be handled by a qualified professional.Type "gG" NH fuse-links are full range breaking capacity fuse-links and are used to protect cables and equipment. They can interrupt any current surge, from the lowest fusing current up to their breaking capacity, and so can be used alone as protection. They also protect electrical devices and industrial set-ups from the electrodynamic effects of very high short-circuit currents.
