Tridonic

Emergency lighting units

Commande uniquement
Prix (hors TVA):
65,16 €
Ce prix est valable jusqu’à la prochaine liste de prix ou jusqu’à épuisement des stocks
EAN: 9006210798622
MPN: 89801003
Colis: 1
Délai de livraison estimé à notre entrepôt: 2-4 weeks

Technical Information

État de l’article Nouveau
Nom du fabricant Emergency lighting units
Marque Tridonic
Catégories Unités de secours pour luminaires
Largeur 30 mm
Hauteur 21 mm
Longueur de la prise 179 mm
Tension nominale 220-240 V
Degré de protection (IP) IP20
Équipement de surveillance Bouton de test

Détails d’emballage

Niveau d’emballage 1 9006210798622, 9006210798622, 9006210798622

Description

Kit with emergency lighting LED driver, battery for 3 h duration and indication LED ¦ For self-contained emergency lighting ¦ For LED modules with a forward voltage of 10 – 54 V ¦ SELV for output voltage < 60 V DC ¦ Low profile casing (21 x 30 mm cross-section) ¦ For luminaire installation ¦ EM = Emergency ¦ 5 years guarantee (conditions at www.tridonic.com) ¦ Non maintained operation ¦ 3 h rated duration ¦ Compatible with all dimmable and non-dimmable constant current LED driver (see data sheet, LED driver compatibility) ¦ 3-pole technology: 2-pole LED module changeover and delayed power switching for the LED driver ¦ Automatic shutdown of output if LED load is out of range ¦ Constant power output ¦ Maximum light output for all LED modules ¦ Electronic charge system ¦ Deep discharge protection ¦ Short-circuit-proof battery connection ¦ Polarity reversal protection for battery ¦ High-temperature cells ¦ LiFePO4 batteries with Tridonic LiFeGuard ¦ 18650 cells ¦ 4 – 8 years design life for LiFePO4 batteries ¦ 3 years guarantee for LiFePO4 batteries (conditions at www.tridonic.com)
