Emergency lighting units image 1
Tridonic

Emergency lighting units

Commande uniquement
Prix (hors TVA):
76,70 €
Ce prix est valable jusqu’à la prochaine liste de prix ou jusqu’à épuisement des stocks
EAN: 9006210759876
MPN: 89800903
Colis: 1
Délai de livraison estimé à notre entrepôt: 2-4 weeks

Technical Information

État de l’article Nouveau
Nom du fabricant Emergency lighting units
Marque Tridonic
Catégories Unités de secours pour luminaires
Largeur 30 mm
Hauteur 21 mm
Puissance 2.3 W
Longueur de la prise 179 mm
Tension nominale 220-240 V
Degré de protection (IP) IP20
Équipement de surveillance Autre
Temps de fonctionnement nominal 1-3 h

Détails d’emballage

Niveau d’emballage 1 9006210759876, 9006210759876, 9006210759876

Description

Emergency lighting LED driver with DALI-2 interface and automatic test function ¦ For self-contained emergency lighting ¦ For LED modules with a forward voltage of 50 – 250 V ¦ Low profile casing (21 x 30 mm cross-section) ¦ For luminaire installation ¦ EM = Emergency ¦ Nominal lifetime up to 100,000 h ¦ 5 years guarantee (conditions at www.tridonic.com) ¦ Non maintained operation ¦ DALI-2 interface for controlled testing and monitoring ¦ 1, 2 or 3 h rated duration ¦ Operating time selectable with plug (duration link) ¦ Compatible with most constant current LED drivers (see data sheet, LED driver compatibility) ¦ 3-pole technology: 2-pole LED module changeover and delayed power switching for the LED driver ¦ Automatic shutdown of output if LED load is out of range ¦ Constant power output ¦ Two-colour status display LED ¦ Electronic charge system ¦ Deep discharge protection ¦ Short-circuit-proof battery connection ¦ Polarity reversal protection for battery provided by 3-pole connector ¦ Automatic detection of the connected battery technology (NiMH or LiFePO4 batteries) ¦ {nobullet} Self-test: ¦ Status of the battery ¦ Status of the LED ¦ Function test ¦ Duration test ¦ High-temperature cells ¦ NiMH or LiFePO4 batteries ¦ LA or 18650 cells ¦ 4-year design life for NiMH batteries ¦ 1 years guarantee for NiMH batteries (conditions at www.tridonic.com) ¦ 4 – 8 years design life for LiFePO4 batteries ¦ 4 years guarantee for LiFePO4 batteries ¦ LiFePO4 batteries with Tridonic LiFeGuard ¦ For battery compatibility refer to data sheet, battery selection
