VIALOX® NAV-T SUPER XT 100W SUPER XT
Discontinued
Not Available
Estimate delivery time to our warehouse: By request
Technical Information
| Item condition | New |
| Manufacture name | VIALOX® NAV-T SUPER XT 100W SUPER XT |
| Brand | OSRAM |
| Country of origin* | CN |
| * The actual country of origin may differ depending on the delivery batch. To confirm the specific country of origin, please contact your account manager. | |
| Harmonized System Code | 8539 3220 00 |
| ETIM | EC000821 |
| Energy Class | F |
| EPREL - European Product Registry for Energy Labelling | 546597 |
| Model | Clear |
| Socket | E40 |
| Luminous flux | 10300 lm |
| Total length | 210 mm |
| Colour rendering index CRI | 20-39 |
| Diameter | 47 mm |
| Lamp efficacy | 103 lm/W |
| Lamp shape | Tube, single-ended |
| External ballast required | Yes |
| Colour temperature | 2000 K |
| Lamp power | 100 W |
Packing details
| Packing level 1 | 4058075803565 |
| Packing level 2 | 4058075803695 |
| Packing level 3 | 4058075803565 |
Other Technical data
| Energy efficiency class | A+ |
| External ignitor required | Yes |
| Mercury-free | No |
| Number of discharge tubes | 0 |
| Lighting for plants | No |
| Replacement for mercury vapour lamp | No |
| Average nominal lifespan | 48000 h |
| Weighted energy consumption in 1000 hours | 110 kWh |
| Lamp designation | T14 |
Downloads
Description
High-pressure sodium vapor lamps for open and enclosed luminaires. Product features: Lamp survival rate: 95 % after 28,000 h burning time. Lamp maintenance factor: ≥ 80 % after 24,000 h burning time (according to DIN 13201). Dimmable on conventional control gears and electronic control gears. Product benefits: Very long lifetime. Very high luminous efficacy. Extended service time (lamp replacement cycle): 8 years (at approx. 11 h/day). Very good luminous flux maintenance throughout the life of the lamp. Optimum energy efficiency on POWERTRONIC® PTo 3DIM ECGs. Areas of application: Streets. Outdoor lighting. Industrial installations. Suitable for use in open and enclosed luminaires. Outdoor applications only in suitable luminaires. Alternative to sodium twin arc lamps.
Replaced by
In stock
10,37 €
Subtotal: 124,44 €
MOQ: 12
Split box: 10,00 €
EAN: 4050300015743
MPN: 4050300015743
Package: 1
Box: 12
