VIALOX® NAV®-T SUPER 4Y® 50…100 W SUPER 4Y

In stock In vendor's stock

Price (excl. VAT):

7,24 €

This price is valid until 31.12.25 or while stock lasts

Split box: 10,00 €

EAN: 4050300015743

MPN: 4050300015743

Package: 1

Box: 12

Estimate delivery time at our warehouse (approx.): 1-4 weeks

Technical Information

Item condition	New
Manufacture name	VIALOX® NAV®-T SUPER 4Y® 50…100 W SUPER 4Y
Brand	OSRAM
Categories	High pressure sodium-vapour lamps E40 Light Bulbs E40 Sodium-vapour Lamps
Country of origin	CN
Harmonized System Code	8539 3220 00
Energy Class	F
EPREL - European Product Registry for Energy Labelling	546581
Model	Clear
Socket	E40
Luminous flux	10300 lm
Total length	210 mm
Colour rendering index CRI	20-39
Diameter	47 mm
Lamp efficacy	103 lm/W
Lamp shape	Tube, single-ended
External ballast required	Yes
Colour temperature	2000 K
Lamp power	100 W

Packing details

Packing level 1	4050300015743
Packing level 2	4050300631806
Packing level 3	4050300015743

Other Technical data

External ignitor required	Yes
Mercury-free	No
Number of discharge tubes	1
Lighting for plants	No
Replacement for mercury vapour lamp	No
Average nominal lifespan	32000 h
Weighted energy consumption in 1000 hours	110 kWh
Lamp designation	T14
Energy efficiency class according to EU regulation 2019/2015	F

Downloads

Others Product data sheet Product data sheet for energy label Declaration DOC CE (Declaration of conformity CE)

Description

High-pressure sodium vapor lamps for open and enclosed luminaires. Product features: Lamp survival factor: 95 % after 16,000 h burning time. Lamp maintenance factor: ≥ 80 % after 16,000 h burning time (according to DIN 13201). Service lifetime: 4 years (at approx. 11 h/day). Dimmable on conventional control gears and electronic control gears. Product benefits: Very high luminous efficacy. Very good luminous flux maintenance throughout the life of the lamp. Energy savings of up to 50 % when replacing mercury vapor lamps (HQL). Optimum energy efficiency on POWERTRONIC® PTo 3DIM ECGs. Areas of application: Streets. Outdoor lighting. Industrial installations. Suitable for use in open and enclosed luminaires. Outdoor applications only in suitable luminaires.
