Spelsberg

Cable gland KVR M16-MGM

Order only
Price (excl. VAT):
1,21 €
This price is valid until 24.12.25
EAN: 4013902012534
MPN: 22741601
Package: 1
Box: 75
Pallet: 48600
Estimate delivery time at our warehouse (approx.): 4-6 weeks

Technical Information

Item condition New
Manufacture name Cable gland KVR M16-MGM
Brand Spelsberg
Categories Standard Cable Glands
Country of origin* DE
* The actual country of origin may differ depending on the delivery batch. To confirm the specific country of origin, please contact your account manager.
Harmonized System Code 3926 9097 00
Model Straight
Thread length 8 mm
Material quality Polyamide (PA)
Thread type Metric
Material Plastic
Hexagon angular dimension 22 mm
Suitable for cable diameter 4-10 mm
Degree of protection (IP) IP68
Nominal thread size inch/gas pipe thread Other
Nominal thread size metric/PG 16

Packing details

Packing level 1 4013902012534
Packing level 2 4013902353767
Packing level 3 4013902012534, 4013902335640
Packing level 4 4013902012534, 4013902335657

Other Technical data

Halogen free Yes
Shock resistant Yes
RAL-number 7035
Surface protection Untreated
Bend radius protection/trumpet flare No
With strain relief Yes
Screened No
EMC-version No
Glass-fibre reinforced Yes
Type of sealing Sealing ring
Operating temperature -25-100 °C
Pitch thread 1.5 mm
Explosion-tested version No
Flat cable coupling No
Multi seal area No
With locknut Yes
Separable screw gland No
For Ex-zone gas None
For Ex-Zone dust None
For armoured cable No
Snapping in opening No
Wrench width 20 mm

Downloads

Product data sheet

Description

Cable gland KVR M16-MGM
