Ultrasonic Sensor Level Control LUS211-130-51-2UPN8-H1141
Order only
Price (excl. VAT):
616,71 €
EAN: 4047101476217
MPN: 100003165
Package: 1
Estimate delivery time at our warehouse (approx.):
4-6 weeks
Technical Information
| Item condition | New |
| Manufacture name | Ultrasonic Sensor Level Control LUS211-130-51-2UPN8-H1141 |
| Brand | TURCK |
| Categories |
Proximity Sensors
|
| Country of origin | DE |
| Harmonized System Code | 8536 5019 00 |
| Housing material | Other |
| Type of electric connection | Plug-in connection |
| Construction type housing | Cylinder plain |
| Supply voltage | 18 V |
| Measuring range length | 130 mm |
Packing details
| Packing level 1 | 4047101476217, 4047101476217 |
Other Technical data
| Ambient temperature | -25 °C |
| Switching frequency | 6.5 Hz |
| Type of switching output | PNP |
| Type of switch function | Programmable/configurable |
| Standard for interfaces | Other |
| No-load current | 150 mA |
| Synchronization possible | No |
| Material active area of sensor | Plastic |
| Diameter sensor | 38 mm |
| Length of sensor | 127.1 mm |
Downloads
Description
Ultrasoonsensor, Niveau, Bedrijfsspanning 18…33 VDC, max. reikwijdte 1300 mm, 4-cijferig, tweekleurig 12-segment display 180° draaibaar, Draaibare behuizing na montage van de procesaansluiting, Procesaansluiting G3/4", Afdichtring meegeleverd (rvs-ring met NBR-afdichting), Dode zone: 13 cm, Reikwijdte: 130 cm, Resolutie: 1 mm, Openingshoek van de geluidskegel: +/- 16°, 2x schakeluitgangen, PNP/NPN, Parametreerbaar N.O. / N.C., Overdracht proceswaarde en parametrering via IO-link
