Ultrasonic Sensor Diffuse Mode Sensor RU40U-M18ES-2UP8X2-H1151
Order only
Price (excl. VAT):
423,64 €
EAN: 4047101370287
MPN: 1610013
Package: 1
Estimate delivery time at our warehouse (approx.):
4-6 weeks
Technical Information
| Item condition | New |
| Manufacture name | Ultrasonic Sensor Diffuse Mode Sensor RU40U-M18ES-2UP8X2-H1151 |
| Brand | TURCK |
| Categories |
Proximity Sensors
|
| Country of origin | DE |
| Harmonized System Code | 8536 5019 00 |
| Housing material | Other |
| Type of electric connection | Plug-in connection |
| Construction type housing | Cylinder, screw-thread |
| Supply voltage | 15 V |
| Measuring range length | 25 mm |
Packing details
| Packing level 1 | 4047101370287, 4047101370287 |
Other Technical data
| Ambient temperature | -25 °C |
| Switching frequency | 10.4 Hz |
| Type of switching output | PNP |
| Type of switch function | Programmable/configurable |
| No-load current | 50 mA |
| Relative linearity deflection | 0.5 % |
| Relative repeat accuracy | 0.15 % |
| Synchronization possible | No |
| Material active area of sensor | Plastic |
| Diameter sensor | 18 mm |
| Length of sensor | 92 mm |
Downloads
Description
Ultrasoonsensor, diffuse sensor, Bedrijfsspanning 15…30 VDC, max. reikwijdte 400 mm, rechthoekig geluidsconverterfront, cilindervormige bouwvorm M18, vergoten, aansluiting via M12 x 1 connector, teachbereik instelbaar met adapter, temperatuurcompensatie, Dode zone: 2,5 cm, Reikwijdte: 40 cm, Resolutie: 0,5 mm, Openingshoek van de geluidskegel: +/- 15°, 2x schakeluitgangen, PNP, parametreerbaar N.O. / N.C.
