SPD 3P pluggable 40kA ind.+cont image 1
Berker

SPD 3P pluggable 40kA ind.+cont

Order only
Price (excl. VAT):
208,77 €
This price is valid until 24.12.25
EAN: 3250615660749
MPN: SPN317
Package: 1
Pallet: 1152
Estimate delivery time at our warehouse (approx.): 4-6 weeks

Technical Information

Item condition New
Manufacture name SPD 3P pluggable 40kA ind.+cont
Brand Berker
Categories Surge Protection Devices (SPD)
Harmonized System Code 8535 4000 00
Voltage protection level 1.5 kV
Nominal discharge surge current (8/20) 20 kA
Nominal voltage AC 400 V
Voltage protection level L-N 1.5 kV
Degree of protection (IP) IP20
Max. PV-voltage 0 V
System configuration DC No
System configuration IT No
System configuration TN No
System configuration TN-C-S No

Packing details

Packing level 1 3250615660749, 3250615660749
Packing level 2 3250615660749
Packing level 3 3250615660749

Other Technical data

Mounting method DIN rail (top hat rail) 35 mm
With remote signalling contact Yes
Max. continuous voltage AC 275 V
Category type 2 Yes
Signalling at the device Optic
Max. continuous voltage DC 0 V
Integrated backup fuse No
System configuration TN-C No
System configuration TN-S No
System configuration TT No
System configuration other Yes
Max. discharge surge current (8/20) 40 kA
Integrated short-circuit protection No
Leakage-current free No

Description

SPD 3P pluggable 40kA class 2 with end of life indicator + remote contact
