Snap-in socket with protruding mating face 4-pole white
In stock: No
Vendor stock: No
Minimal order quantity: 100
Price (excl. VAT):
2,08 €
Subtotal: 208,00 €
MOQ: 100
EAN: 4045454655099
MPN: 770-724/009-000
Box: 100
Estimate delivery time at our warehouse (approx.):
4-6 weeks
Technical Information
| Item condition | New |
| Manufacture name | Snap-in socket with protruding mating face 4-pole white |
| Brand | WAGO |
| Categories |
Device Connectors
|
| Country of origin | DE |
| Harmonized System Code | 8536 6990 00 |
| Model | Bus |
| Connection type | Spring clamp connection |
| Locking mechanism | Separate |
| Rated current | 25 A |
| Rated voltage | 400 V |
| Number of poles | 4 |
| Housing material | Polyamide (PA) |
| Surface treatment contacts | Other |
| Contact material | Other |
| Degree of protection (IP) | IP20 |
| Colour coding/contact insert | White |
Packing details
| Packing level 1 | 4045454655099 |
Other Technical data
| Width | 40 mm |
| Halogen free | Yes |
| Height | 18.5 mm |
| Colour housing | White |
| Length | 36.3 mm |
| Pollution degree | 3 |
| Angle of plug | Straight |
| Mechanical coding | Yes |
| Rated surge voltage | 6 kV |
| Continuity resistor | 0.5 mOhm |
| Connection size thread | No thread connection |
| Angle of inclination | 0 ° |
| Number of connections per pole | 2 |
| Built-in version | Snap-in/screw-in device |
| Colour of the separate adapter piece | Without adapter piece |
| Connection cross section (fine-strand) | 0.5-4 mm² |
| Connection cross section (solid-core) | 0.5-4 mm² |
| Max. continuous temperature resistance contact part | 85 °C |
| Max. continuous temperature resistance strain relief | 105 °C |
Description
Snap-in socket with protruding mating face 4-pole Cod. A 4,00 mm² white
