Snap-in socket 2-pole Cod. B gray

Name: Snap-in socket 2-pole Cod. B gray
Brand: WAGO
Price: 1.470 EUR
Availability: PreOrder

In stock: No Vendor stock: No Minimal order quantity: 50

Price (excl. VAT):

1,47 €

This price is valid until 24.12.25

Subtotal: 73,50 € MOQ: 50

EAN: 4055143428200

MPN: 890-742

Package: 1

Box: 50

Estimate delivery time at our warehouse (approx.): 4-6 weeks

Technical Information

Item condition	New
Manufacture name	Snap-in socket 2-pole Cod. B gray
Brand	WAGO
Categories	Device Connectors
Country of origin	DE
Harmonized System Code	8536 6990 00
Model	Bus
Connection type	Spring clamp connection
Locking mechanism	Integrated in plug-in connector
Rated current	16 A
Rated voltage	250 V
Number of poles	2
Housing material	Polyamide (PA)
Surface treatment contacts	Other
Contact material	Other
Degree of protection (IP)	IP20
Pole codification	1, 2
Colour coding/contact insert	Grey

Packing level 1	4055143428200
Packing level 2	4055143428200

Width	19.8 mm
Halogen free	Yes
Height	16 mm
Colour housing	Grey
Length	32.6 mm
Pollution degree	3
Angle of plug	Straight
Mechanical coding	No
Rated surge voltage	4 kV
Continuity resistor	0.5 mOhm
Connection size thread	No thread connection
Angle of inclination	0 °
Number of connections per pole	1
Built-in version	Snap-in/screw-in device
Colour of the separate adapter piece	Without adapter piece
Connection cross section (fine-strand)	0.25-1.5 mm²
Connection cross section (solid-core)	0.25-1.5 mm²
Max. continuous temperature resistance contact part	85 °C
Max. continuous temperature resistance strain relief	105 °C
