Relay module Nominal input voltage: 24 V AC/DC 1 changeover contact gr

Name: Relay module Nominal input voltage: 24 V AC/DC 1 changeover contact gr
Brand: WAGO
Price: 29.820 EUR
Availability: PreOrder

Order only Minimal order quantity: 5

Price (excl. VAT):

29,82 €

This price is valid until 24.12.26

Subtotal: 149,10 € MOQ: 5

EAN: 4055143559119

MPN: 288-504

Package: 1

Box: 5

Estimate delivery time at our warehouse (approx.): 4-6 weeks

Technical Information

Item condition	New
Manufacture name	Relay module Nominal input voltage: 24 V AC/DC 1 changeover contact gr
Brand	WAGO
Categories	Relay AC 24v Relay DC 24v
Country of origin*	CN
* The actual country of origin may differ depending on the delivery batch. To confirm the specific country of origin, please contact your account manager.
Harmonized System Code	8536 4900 00
Nominal current	6 A
Type of switch contact	Single contact
Type of electric connection	Spring clamp connection
Rated control supply voltage at AC 50 Hz	24 V
Degree of protection (IP)	IP20
With LED indication	No
Voltage type for actuating	AC/DC
Number of contacts as normally closed contact	0
Number of contacts as normally open contact	0

Packing level 1	4055143559119
Packing level 2	4055143559119

Width	20.5 mm
Height	48 mm
Depth	85 mm
With detachable clamps	No
Drive, polarization	Polarity free
Drive, switching attitude	Mono stable
With forced-guided contacts	No
Complete with socket	Yes
Rated control supply voltage at AC 60 Hz	24 V
Rated control supply voltage at DC	24 V
Material of contact surface	Silver
Number of contacts as change-over contact	1
