Pressure Transmitter With 2 Switching Outputs and IO-Link  PT1.6A-1001-IOL-H1141 image 1
TURCK

Pressure Transmitter With 2 Switching Outputs and IO-Link  PT1.6A-1001-IOL-H1141

Order only
Price (excl. VAT):
241,34 €
This price is valid until 24.12.25
EAN: 4047101580174
MPN: 100031977
Package: 1
Estimate delivery time at our warehouse (approx.): 4-6 weeks

Technical Information

Item condition New
Manufacture name Pressure Transmitter With 2 Switching Outputs and IO-Link  PT1.6A-1001-IOL-H1141
Brand TURCK
Categories Pressure Sensors
Country of origin* CH
* The actual country of origin may differ depending on the delivery batch. To confirm the specific country of origin, please contact your account manager.
Harmonized System Code 9026 2020 00
Switch off pressure 1.6 bar
Bursting pressure 4.8 bar
Engaging pressure 0 bar
Max. test pressure 4.8 bar
Medium temperature -40 °C

Packing details

Packing level 1 4047101580174, 4047101580174

Other Technical data

Initial setting 0 hPa
End setting 1600 hPa
Type of electric connection Other
Degree of protection (IP) IP67
Initial value measuring range pressure 0 Pa
Rated voltage Ue at DC 18 V
End value measuring range pressure 160000 Pa

Downloads

Product data sheet

Description

Druktransmitter, Met 2 schakeluitgangen en IO-link, Bedrijfsspanning 18…33 VDC, Keramische meetcel, Compacte en robuuste constructie, Uitstekende EMC-eigenschappen, drukbereik 0 … 1,6 bar abs., 18…33 VDC, N.O./N.C., 2x PNP/NPN-uitgangen, IO-link, Procesaansluiting G1/4", binnendraad, vooraan afdichtend, Apparaat met stekker, M12 × 1
