Pressure Sensor (Rotatable) With Analog Output and PNP/NPN Transistor Switching Output PS003A-504-LI2UPN8X-H1141
In stock: No
Vendor stock: No
Minimal order quantity: 1
Price (excl. VAT):
695,16 €
EAN: 4047101241365
MPN: 6832847
Package: 1
Estimate delivery time at our warehouse (approx.):
4-6 weeks
Technical Information
| Item condition | New |
| Manufacture name | Pressure Sensor (Rotatable) With Analog Output and PNP/NPN Transistor Switching Output PS003A-504-LI2UPN8X-H1141 |
| Brand | TURCK |
| Categories |
Pressure Sensors
|
| Country of origin | DE |
| Harmonized System Code | 9026 2020 00 |
| Switch off pressure | 2.5 bar |
| Bursting pressure | 7 bar |
| Engaging pressure | 0 bar |
| Suitable as 2-point controller | No |
| Suitable as limiter | No |
| Suitable as guard | No |
| Max. test pressure | 7 bar |
| Medium temperature | -40 °C |
Packing details
| Packing level 1 | 4047101241365, 4047101241365 |
Other Technical data
| With manual on/off switch | No |
| Initial setting | 0 hPa |
| End setting | 2500 hPa |
| Type of electric connection | Other |
| Explosion-proof | No |
| Degree of protection (IP) | IP67 |
| Initial value measuring range pressure | 0 Pa |
| Rated voltage Ue at DC | 18 V |
| Electronic version | No |
| End value measuring range pressure | 250000 Pa |
| With hand operation | No |
| Adjustable current range | 4 A |
Downloads
Description
druksensor (draaibaar), Met analoge uitgang en een transistorschakeluitgang pnp/npn, uitgang 2 programmeerbaar als schakeluitgang, Bedrijfsspanning 18…30 VDC, draaibare behuizing na montage van de procesaansluiting, aflezen van de ingestelde waarden mogelijk zonder werktuig, programmeerbeveiliging door verzonken toets en Lock-functie, permanente weergave van de drukeenheid (bar, psi, kPa, MPa, misc), drukpiekgeheugen, drukbereik 0 … 2,5 bar abs.
