Pressure Sensor Relative Pressure: 0…100 Bar PS510-100-04-LI2UPN8-H1141
In stock: No
Vendor stock: No
Minimal order quantity: 1
Price (excl. VAT):
468,35 €
EAN: 4047101555318
MPN: 100001575
Package: 1
Estimate delivery time at our warehouse (approx.):
4-6 weeks
Technical Information
| Item condition | New |
| Manufacture name | Pressure Sensor Relative Pressure: 0…100 Bar PS510-100-04-LI2UPN8-H1141 |
| Brand | TURCK |
| Categories |
Pressure Sensors
|
| Country of origin | PL |
| Harmonized System Code | 9026 2020 00 |
| Switch off pressure | 100 bar |
| Bursting pressure | 400 bar |
| Engaging pressure | 0 bar |
| Suitable as 2-point controller | No |
| Suitable as limiter | No |
| Suitable as guard | No |
| Max. test pressure | 300 bar |
| Medium temperature | -30 °C |
Packing details
| Packing level 1 | 4047101555318, 4047101555318 |
Other Technical data
| With manual on/off switch | No |
| Initial setting | 0 hPa |
| End setting | 100000 hPa |
| Type of electric connection | Other |
| Explosion-proof | No |
| Degree of protection (IP) | IP66 |
| Initial value measuring range pressure | 0 Pa |
| Rated voltage Ue at DC | 18 V |
| Electronic version | No |
| End value measuring range pressure | 10000000 Pa |
| With hand operation | No |
| Adjustable current range | 4 A |
Downloads
Description
Druksensor, Relatieve druk: 0…100 bar, Bedrijfsspanning 18…33 VDC, 4-cijferig, tweekleurig 12-segment display 180° draaibaar, Draaibare behuizing na montage van de procesaansluiting, Metalen meetcel, 18…33 VDC, N.O./N.C., PNP/NPN‐uitgang, analoge uitgang (stroom/spanning), IO-link, Procesaansluiting G1/4" buitendraad, Apparaat met stekker, M12 × 1
