Power Cable, PUR Power cable according to AIDA  AIDA-GP-AIDA-GP-52-2M image 1
TURCK

Power Cable, PUR Power cable according to AIDA  AIDA-GP-AIDA-GP-52-2M

Order only
Price (excl. VAT):
133,20 €
This price is valid until 24.12.25
EAN: 4047101406955
MPN: 6935645
Package: 1
Estimate delivery time at our warehouse (approx.): 4-6 weeks

Technical Information

Item condition New
Manufacture name Power Cable, PUR Power cable according to AIDA  AIDA-GP-AIDA-GP-52-2M
Brand TURCK
Categories Circular Connectors
Country of origin DE
Harmonized System Code 8544 4290 00
Rated voltage 24 V
Contact type Pin
Ambient temperature -40 °C
Degree of protection (IP), mounted IP65/IP67
Rated current In 16 A

Packing details

Packing level 1 4047101406955, 4047101406955

Other Technical data

Housing material Zinc
Material of contact surface Gold
Pollution degree 3
Type of housing Straight
With protective conductor No

Downloads

Product data sheet

Description

Voedingsleiding / PUR, aansluitkabel conform AIDA, Nominale spanning 24 V, Kabellengte 2 m, Push-Pull Power connector, 4-polig + PE, voedingskabel: 5 x 2.5 mm2, mantelmateriaal: PUR, kleur: grijs, manteldiameter: 10 mm, geleideropbouw: fijndradig conform VDE 0295, klasse 5 / IEC 60228 CI.5, oliebestendig, slijtagebestendig en bestand tegen inkerven, hydrolysebestendig en bestand tegen microben, RoHS-conform, AIDA-conform, beschermingsklasse IP65 en IP67
