PCB terminal block Locking slides 0.5 mm² blue
In stock: No
Vendor stock: No
Minimal order quantity: 100
Price (excl. VAT):
0,67 €
Subtotal: 67,00 €
MOQ: 100
EAN: 4044918877565
MPN: 218-102/000-006
Package: 1
Estimate delivery time at our warehouse (approx.):
4-6 weeks
Technical Information
| Item condition | New |
| Manufacture name | PCB terminal block Locking slides 0.5 mm² blue |
| Brand | WAGO |
| Categories |
PCB Connectors & Terminals
|
| Country of origin | PL |
| Harmonized System Code | 8536 9010 00 |
| Rated voltage | 160 V |
| Number of levels | 1 |
| Rated surge voltage | 2.5 kV |
| Angle PCB/conductor connection | Other |
| Rated current In | 6 A |
| Number of electrical connections | 24 |
Packing details
| Packing level 1 | 4044918877565 |
Other Technical data
| Height | 8.1 mm |
| Colour housing | Grey |
| Operating temperature | -60-105 °C |
| Type of fastening | Solder |
| Inflammability class of insulation material according to with UL94 | V0 |
| Over voltage category | III |
| Pollution degree | 2 |
| Connection type conductor | Spring clamp connection |
| Connection type PCB | Soldering connection |
| Diameter connection pin | 0 mm |
| Length pin | 2.8 mm |
| Material connection surface | Tin |
| Modular spacing connections | 2.5 mm |
| Type of banding | None |
| Connectable conductor cross section solid-core | 0.08-0.5 mm² |
| Connectable conductor cross section fine-strand with cable end sleeve | 0.25 mm² |
| Connectable conductor cross section fine-strand without cable end sleeve | 0.08-0.5 mm² |
| Connectable conductor cross section multi-wired | 0.08-0.5 mm² |
| Material insulation body | Thermoplastic |
| Type of PCB fastening | Connecting contact |
Description
PCB terminal block Locking slides 0.5 mm² Pin spacing 2.5 mm 2-pole CAGE CLAMP® 0,50 mm² blue
