PCB Terminal Block 2-Pole, 6 mm², 7.5 mm Pitch, Lever

Order only Minimal order quantity: 120

EAN: 4055144086720

MPN: 2606-1102/000-006

Package: 1

Price (excl. VAT)

1,86 €

per unit

MOQ: 120

EDT to our warehouse: 4-6 weeks

Price valid until 24.12.26 or while in stock

Technical Information

Item condition	New
Manufacture name	PCB terminal block lever 6 mm² blue
Brand	WAGO
Categories	PCB Connectors & Terminals
Country of origin*	PL
* The actual country of origin may differ depending on the delivery batch. To confirm the specific country of origin, please contact your account manager.
Harmonized System Code	8536 9010 00
ETIM	EC002643
Rated voltage	1000 V
Number of levels	1
Rated surge voltage	8 kV
Angle PCB/conductor connection	0°/180° (horizontal)
Rated current In	41 A
Number of electrical connections	2

Packing level 1

4055144086720

Height	24 mm
Colour housing	Blue
Operating temperature	-60-105 °C
Type of fastening	Solder
Inflammability class of insulation material according to with UL94	V0
Over voltage category	III
Pollution degree	2
Connection type conductor	Spring clamp connection
Connection type PCB	Soldering connection
Diameter connection pin	0 mm
Length pin	4 mm
Material connection surface	Tin
Modular spacing connections	7.5 mm
Type of banding	None
Connectable conductor cross section solid-core	0.2-10 mm²
Connectable conductor cross section fine-strand with cable end sleeve	0.25-6 mm²
Connectable conductor cross section fine-strand without cable end sleeve	0.2-10 mm²
Connectable conductor cross section multi-wired	0.2-10 mm²
Material insulation body	Polyamide (PA)
Type of PCB fastening	Connecting contact

PCB terminal block lever 6 mm² Pin spacing 7.5 mm 2-pole Push-in CAGE CLAMP® 6,00 mm² blue
