PCB terminal block lever 4 mm² gray
Order only
Minimal order quantity: 30
Price (excl. VAT):
6,35 €
Subtotal: 190,50 €
MOQ: 30
EAN: 4055143564397
MPN: 2604-1112
Box: 30
Estimate delivery time at our warehouse (approx.):
4-6 weeks
Technical Information
| Item condition | New |
| Manufacture name | PCB terminal block lever 4 mm² gray |
| Brand | WAGO |
| Categories |
PCB Connectors & Terminals
|
| Country of origin* | DE |
| * The actual country of origin may differ depending on the delivery batch. To confirm the specific country of origin, please contact your account manager. | |
| Harmonized System Code | 8536 9010 00 |
| Rated voltage | 400 V |
| Number of levels | 1 |
| Rated surge voltage | 4 kV |
| Angle PCB/conductor connection | 0°/180° (horizontal) |
| Rated current In | 32 A |
| Number of electrical connections | 12 |
Packing details
| Packing level 1 | 4055143564397 |
Other Technical data
| Height | 16.7 mm |
| Colour housing | Grey |
| Operating temperature | -60-105 °C |
| Type of fastening | Solder |
| Inflammability class of insulation material according to with UL94 | V0 |
| Over voltage category | III |
| Pollution degree | 2 |
| Connection type conductor | Spring clamp connection |
| Connection type PCB | Soldering connection |
| Length pin | 4 mm |
| Material connection surface | Tin |
| Modular spacing connections | 5 mm |
| Type of banding | None |
| Connectable conductor cross section solid-core | 0.2-4 mm² |
| Connectable conductor cross section fine-strand with cable end sleeve | 0.25-2.5 mm² |
| Connectable conductor cross section fine-strand without cable end sleeve | 0.25-2.5 mm² |
| Connectable conductor cross section multi-wired | 0.2-4 mm² |
| Material insulation body | Thermoplastic |
| Type of PCB fastening | Connecting contact |
Description
PCB terminal block lever 4 mm² Pin spacing 5 mm 12-pole Push-in CAGE CLAMP® 4,00 mm² gray
