Magnetic Field Sensor Magnetic-inductive Proximity Sensor  BIM-EG08-AN6X image 1
TURCK

Magnetic Field Sensor Magnetic-inductive Proximity Sensor  BIM-EG08-AN6X

In stock: No Vendor stock: No Minimal order quantity: 1
Price (excl. VAT):
124,50 €
This price is valid until 24.12.25
EAN: 4047101156195
MPN: 4621300
Package: 1
Estimate delivery time at our warehouse (approx.): 4-6 weeks

Technical Information

Item condition New
Manufacture name Magnetic Field Sensor Magnetic-inductive Proximity Sensor  BIM-EG08-AN6X
Brand TURCK
Categories Proximity Sensors
Country of origin PL
Harmonized System Code 8536 5019 00
Voltage type DC
Housing material Stainless steel
Suitable for safety functions No
Switching distance 78 mm
Type of electric connection Cable
Type of switching output NPN
Construction type housing Cylinder, screw-thread
Degree of protection (IP) IP67
Rated supply voltage at DC 10 V

Packing details

Packing level 1 4047101156195, 4047101156195

Other Technical data

Ambient temperature -25 °C
With monitoring function downstream switching devices No
Cross-/short circuit identification possible Yes
Type of actuation Magnet
Diameter sensor 8 mm
Length of sensor 41.6 mm

Downloads

Product data sheet

Description

Magneetveldsensor, magneetinductieve naderingssensor, Bedrijfsspanning 10…30 VDC, Nominale schakelafstand 78 mm, Kabellengte 2 m, schroefdraad, M8 x 1, roestvast staal, 1.4427 SO, nominale schakelafstand 78 mm, in combinatie met magneet DMR31-15-5, DC 3-draads, 10...30 VDC, N.O., NPN-uitgang, kabelaansluiting
