Inductive Sensor Dual Sensors with Extended Temperature Range NI4-DSU35TC-2Y1X2/S97
Order Only
Minimal order quantity: 1
Price (excl. VAT):
212,21 €
EAN: 4047101199765
MPN: 1051017
Package: 1
Estimate delivery time at our warehouse (approx.):
4-6 weeks
Technical Information
| Item condition | New |
| Manufacture name | Inductive Sensor Dual Sensors with Extended Temperature Range NI4-DSU35TC-2Y1X2/S97 |
| Brand | TURCK |
| Categories |
Proximity Sensors
|
| Country of origin | DE |
| Harmonized System Code | 8536 5019 00 |
| Voltage type | DC |
| Switching distance | 4 mm |
| Type of electric connection | Clamp |
| Type of switching output | NAMUR |
| Mechanical mounting condition for sensor | Not flat |
| Performance level according to EN ISO 13849-1 | Level c |
| SIL according to IEC 61508 | None |
Packing details
| Packing level 1 | 4047101199765, 4047101199765 |
Other Technical data
| Cascadable | No |
| Housing material | Plastic |
| Suitable for safety functions | No |
| Coating housing | Other |
| Switching frequency | 50 Hz |
| Explosion safety category for gas | ATEX gas-ex-protection, Cat. 2G |
| Explosion safety category for dust | ATEX dust-ex-protection, Cat. 1D |
| With monitoring function downstream switching devices | No |
| Type of actuation | Metallic Target |
| Width sensor | 60 mm |
| Compression-resistant | No |
| Height of sensor | 35.4 mm |
| Length of sensor | 62 mm |
Downloads
Description
Inductieve sensor, dubbelsensor met uitgebreid temperatuurbereik, Nominale schakelafstand 4 mm, Niet-bondig, rechthoekig, bouwvorm DSU35, kunststof, PP-GF30-VO, twee uitgangen voor de detectie van de positie van de klepstanden, montage op alle standaardaandrijvingen, voor temperaturen tot -40°C, DC 2-draads, nom. 8,2 VDC, 2 x uitgang volgens DIN EN 60947-5-6 (NAMUR), Aansluitklemmenruimte, ATEX-categorie II 2 G, Ex-zone 1, ATEX-categorie II 1 D, Ex-zone 20 voor temperaturen tot -25 °C, SIL 2 conform IEC 61508
