Incremental Encoder Industrial Line  REI-43H38S-2B360-H1181 image 1
TURCK

Incremental Encoder Industrial Line  REI-43H38S-2B360-H1181

Order Only Minimal order quantity: 1
Price (excl. VAT):
690,66 €
This price is valid until 24.12.25
EAN: 4047101547634
MPN: 100011432
Package: 1
Estimate delivery time at our warehouse (approx.): 4-6 weeks

Technical Information

Item condition New
Manufacture name Incremental Encoder Industrial Line  REI-43H38S-2B360-H1181
Brand TURCK
Categories Rotary Encoders
Country of origin DE
Harmonized System Code 9031 8020 00
Model Incremental encoder
Housing material Other
Max. pulses per revolution 300
Type of electric connection Plug-in connection
Degree of protection (IP) IP65
Type of shaft encoder Hollow shaft
Diameter axle 38 mm

Packing details

Packing level 1 4047101547634, 4047101547634

Other Technical data

Programmable No
Standard for interfaces Other
Impulse rate per cycle 360
Physical measurement principle Optic

Downloads

Product data sheet

Description

Incrementele encoder, Industrial-Line, Bedrijfsspanning 10…30 VDC, Resolutie incrementeel 360 ppr, Flens zonder bevestigingselement, Ø 100 mm, Holle as, Ø 38 mm, Optisch meetprincipe, Asmateriaal: roestvast staal, Beschermingsklasse IP65 huis- en aszijde, ‐40 … +80 °C, Max. 6000 omwentelingen/min (bij 60 °C: 2500 omw/min, 10…30 V DC, Push-pull/HTL met omgekeerd signaal, Impulsfrequentie max. 300 kHz, Connector, M12 × 1, 8‐polig, 360 impulsen per omwenteling
