Differential Pressure Sensor 2 PNP/NPN Transistor Switching Outputs PS040D-502T-2UPN8X-H1141
In stock: No
Vendor stock: No
Minimal order quantity: 1
Price (excl. VAT):
936,14 €
EAN: 4047101431025
MPN: 6834118
Package: 1
Estimate delivery time at our warehouse (approx.):
4-6 weeks
Technical Information
| Item condition | New |
| Manufacture name | Differential Pressure Sensor 2 PNP/NPN Transistor Switching Outputs PS040D-502T-2UPN8X-H1141 |
| Brand | TURCK |
| Categories |
Pressure Sensors
|
| Country of origin | DE |
| Harmonized System Code | 9026 2020 00 |
| Switch off pressure | 40 bar |
| Bursting pressure | 200 bar |
| Engaging pressure | 0 bar |
| Suitable as 2-point controller | No |
| Suitable as limiter | No |
| Suitable as guard | No |
| Max. test pressure | 200 bar |
| Medium temperature | -40 °C |
Packing details
| Packing level 1 | 4047101431025, 4047101431025 |
Other Technical data
| With manual on/off switch | No |
| Initial setting | 0 hPa |
| End setting | 40000 hPa |
| Type of electric connection | Other |
| Explosion-proof | No |
| Degree of protection (IP) | IP67 |
| Initial value measuring range pressure | 0 Pa |
| Rated voltage Ue at DC | 18 V |
| Electronic version | No |
| End value measuring range pressure | 4000000 Pa |
| With hand operation | No |
Downloads
Description
Differentiële druksensor, met 2 transistorschakeluitgangen pnp/npn, Bedrijfsspanning 18…30 VDC, Drukbewaking onder ruwe industriële omstandigheden, draaibare behuizing na montage van de procesaansluiting, aflezen van de ingestelde waarden mogelijk zonder werktuig, High-Side switch, Programmeerbeveiliging door verzonken toets, Lock-functie en wachtwoordcontrole, permanente weergave van de drukeenheid (bar, psi, kPa, MPa, misc), drukpiekgeheugen, Drukbereik 0 … 40 bar verschil
