Actuator and Sensor Cable Verbindungsleitung RSM RKM 30-2M

Name: Actuator and Sensor Cable Verbindungsleitung RSM RKM 30-2M
Brand: TURCK
Price: 80.080 EUR
Availability: PreOrder

Order only

Price (excl. VAT):

80,08 €

This price is valid until 24.12.26

EAN: 4047101050158

MPN: U2255

Package: 1

Estimate delivery time at our warehouse (approx.): 4-6 weeks

Technical Information

Item condition	New
Manufacture name	Actuator and Sensor Cable Verbindungsleitung RSM RKM 30-2M
Brand	TURCK
Categories	Circular Connectors
Country of origin*	MX
* The actual country of origin may differ depending on the delivery batch. To confirm the specific country of origin, please contact your account manager.
Harmonized System Code	8544 4290 00
Rated voltage	600 V
Contact type	Pin
Ambient temperature	-40 °C
Degree of protection (IP), mounted	IP67
Rated current In	9 A

Packing details

Packing level 1

4047101050158, 4047101050158

Other Technical data

Housing material	Plastic
Material of contact surface	Gold
Pollution degree	3
Type of housing	Straight
With protective conductor	No

Downloads

Product data sheet

Description

Voedingskabel, PVC-kabelmantel, Nominale spanning 600 V, Kabellengte 2 m, Voedingskabel: 3x 0,83 mm2, 3x 18 AWG, Mantelmateriaal: PVC, Mantelkleur: geel, Manteldiameter: 6,2 mm, UV-bestendig, Onontvlambaar volgens CSA FT4, UL, CSA gecertificeerd, RoHS-conform, Beschermingsklasse: NEMA 1, 3, 4, 6P en IEC IP67, Contraconnector recht 7/8", Connector recht 7/8", kabellengte: 2.0 meter, 7/8″-connector, recht, 3-polig, 7/8″ Minifast-contraconnector, recht, Tray-kabel voor instrumentatie, PVC-buitenmantel, geel, 3 × 18 AWG, UV-bestendig, -40 °C koude buigsterkte, Oliebestendig, Brandklassen: UL 1685 FT4, UL1061, CSA FT4, Flexlife® en C-Track goedgekeurd
