2-Way Splitter Y-Splitter with Cable, Female M12 × 1 - 2x Male M8 × 1  VBRK4.4-2PSW3M-1.5/1.5/TXL image 1
TURCK

2-Way Splitter Y-Splitter with Cable, Female M12 × 1 - 2x Male M8 × 1  VBRK4.4-2PSW3M-1.5/1.5/TXL

Order Only
Price (excl. VAT):
65,94 €
This price is valid until 24.12.25
EAN: 4047101375343
MPN: 6630404
Package: 1
Estimate delivery time at our warehouse (approx.): 4-6 weeks

Technical Information

Item condition New
Manufacture name 2-Way Splitter Y-Splitter with Cable, Female M12 × 1 - 2x Male M8 × 1  VBRK4.4-2PSW3M-1.5/1.5/TXL
Brand TURCK
Categories Pre-wired Sensor/Actuator Module
Country of origin CN
Harmonized System Code 8544 4290 00
Rated voltage 48 V
Operating voltage 48 V
Length of the preassembled cable 1.5 m

Packing details

Packing level 1 4047101375343, 4047101375343

Other Technical data

Operating temperature -50 °C
With potential separation No
Material of contact surface Gold
Degree of protection (IP) IP67
With LED indication No
Pollution degree 3
Connection for NPN-sensors No
Cable length configurable No
Fix cable version suitable for cable guide chain No
Material insulation body Other
Material contact body Brass

Downloads

Product data sheet

Description

2-weg splitter, Y-verdeler met kabel, contraconnector M12 × 1 - 2x connector M8 × 1, Nominale spanning 48 V, Kabellengte 1.5 m, Mantelmateriaal: PUR, Mantelkleur: zwart, Geschikt voor sleepkettingen, Chemicaliën-, UV- en oliebestendig, Vlamwerend (FT2 conform UL 1581, IEC 60332-2-2), Halogeen-, siliconen-, PVC- en LABS-vrij, Bijzonder slijtvast, RoHS-conform, Beschermingsklasse: IP67, 4/3-polig, Kabellengte: 1,5 / 1,5 meter
