WAGO

2-conductor PCB terminal block 1.5 mm² Pin spacing 5 mm gray

Order only Minimal order quantity: 35
Price (excl. VAT):
1,24 €
This price is valid until 24.12.25
Subtotal: 43,40 € MOQ: 35
EAN: 4044918689366
MPN: 253-106
Package: 1
Box: 35
Estimate delivery time at our warehouse (approx.): 4-6 weeks

Technical Information

Item condition New
Manufacture name 2-conductor PCB terminal block 1.5 mm² Pin spacing 5 mm gray
Brand WAGO
Categories PCB Connectors & Terminals
Country of origin* CN
* The actual country of origin may differ depending on the delivery batch. To confirm the specific country of origin, please contact your account manager.
Harmonized System Code 8536 9010 00
Rated voltage 320 V
Number of levels 1
Rated surge voltage 4 kV
Angle PCB/conductor connection Other
Rated current In 17.5 A
Number of electrical connections 6

Packing details

Packing level 1 4044918689366
Packing level 2 4044918689366
Packing level 3 4044918689366

Other Technical data

Height 13 mm
Colour housing Grey
Operating temperature -60-105 °C
Type of fastening Solder
Inflammability class of insulation material according to with UL94 V0
Over voltage category III
Pollution degree 2
Connection type conductor Push-in clamp connection
Connection type PCB Soldering connection
Length pin 4 mm
Material connection surface Tin
Modular spacing connections 5 mm
Type of banding None
Connectable conductor cross section solid-core 0.5-1.5 mm²
Material insulation body Thermoplastic
Type of PCB fastening Connecting contact

Description

2-conductor PCB terminal block 1.5 mm² Pin spacing 5 mm 6-pole PUSH WIRE® 1,50 mm² gray
