WAGO

2250-321 2-conductor miniature through terminal block; with push-button; 1 mm²

Order only Minimal order quantity: 100
Price (excl. VAT):
0,56 €
This price is valid until 24.12.25
Subtotal: 56,00 € MOQ: 100
EAN: 4055143965187
MPN: 2250-321
Package: 1
Box: 100
Estimate delivery time at our warehouse (approx.): 4-6 weeks

Technical Information

Item condition New
Manufacture name 2250-321 2-conductor miniature through terminal block; with push-button; 1 mm²
Brand WAGO
Categories Terminal Block Accessories
Country of origin DE
Harmonized System Code 8536 9010 00
Rated voltage 500 V
Rated current In 13.5 A
Explosion-tested version 'Ex e' FALSE

Packing details

Packing level 1 4055143965187
Packing level 2 4055143965187

Other Technical data

Mounting method Other
Colour Grey
Width 3.5 mm
Halogen free Yes
Height 33.2 mm
Depth 27.2 mm
Number of poles 1
Operating temperature 105 °C
Number of clamp positions per pole 2
Inflammability class of insulation material according to with UL94 V0
Closing plate required TRUE
Type of electrical connection 1 Spring clamp connection
Type of electrical connection 2 Spring clamp connection
Transparent FALSE
Connectable conductor cross section solid-core 0.14-1.5 mm²
Connectable conductor cross section fine-strand with cable end sleeve 0.5-0.75 mm²
Connectable conductor cross section fine-strand without cable end sleeve 0.14-1.5 mm²
Connectable conductor cross section multi-wired 0.14-1 mm²
Material insulation body Thermoplastic

Description

2-conductor miniature through terminal block; with push-button; 1 mm²; Center terminal block without snap-in mounting foot, without mounting flange; side and center marking; with test port; Push-in CAGE CLAMP®; 1,00 mm²; gray
