2-conductor carrier terminal block for DIN-rail 35 x 15 and 35 x 7.5 2

Order only Minimal order quantity: 50

Price (excl. VAT):

5,55 €

This price is valid until 24.12.25

Subtotal: 277,50 € MOQ: 50

EAN: 4055143072311

MPN: 2002-1568

Box: 50

Estimate delivery time at our warehouse (approx.): 4-6 weeks

Technical Information

Item condition	New
Manufacture name	2-conductor carrier terminal block for DIN-rail 35 x 15 and 35 x 7.5 2
Brand	WAGO
Categories	DIN Rail Terminal Blocks
Country of origin*	DE
* The actual country of origin may differ depending on the delivery batch. To confirm the specific country of origin, please contact your account manager.
Harmonized System Code	8536 9010 00
Mounting method	DIN rail (top hat rail) 35 mm
Rated voltage	400 V
Type of electrical connection 1	Spring clamp connection
Type of electrical connection 2	Spring clamp connection
Number of levels	1
Number of clamp positions per level	2
Connectable conductor cross section solid-core	0.75-4 mm²
Connectable conductor cross section fine-strand with cable end sleeve	0.75-2.5 mm²
Connectable conductor cross section fine-strand without cable end sleeve	0.25-4 mm²
Connectable conductor cross section multi-wired	0.25-2.5 mm²
Rated current In	16 A

Packing level 1

4055143072311

Colour	White
Width	5.2 mm
Height	99.6 mm
Depth	32.9 mm
Operating temperature	105 °C
Inflammability class of insulation material according to with UL94	V0
Closing plate required	Yes
Internally connected stages	FALSE
Material insulation body	Thermoplastic
Explosion-tested version 'Ex e'	No

2-conductor carrier terminal block for DIN-rail 35 x 15 and 35 x 7.5 2.5 mm² Push-in CAGE CLAMP® 2,50 mm² white
