1-conductor female connector Push-in CAGE CLAMP® 4 mm² green-yellow

In stock: No Vendor stock: No Minimal order quantity: 200

Price (excl. VAT):

1,25 €

This price is valid until 24.12.25

Subtotal: 250,00 € MOQ: 200

EAN: 4050821089872

MPN: 2022-101/132-016

Box: 200

Estimate delivery time at our warehouse (approx.): 4-6 weeks

Technical Information

Item condition	New
Manufacture name	1-conductor female connector Push-in CAGE CLAMP® 4 mm² green-yellow
Brand	WAGO
Categories	Terminal Block Accessories
Country of origin	DE
Harmonized System Code	8536 6990 00
Rated voltage	690 V
Rated current In	24 A
Explosion-tested version 'Ex e'	No

Packing level 1

4050821089872

Mounting method	Other
Colour	Green
Width	5.2 mm
Halogen free	Yes
Height	22.4 mm
Depth	56.5 mm
Number of poles	1
Operating temperature	105 °C
Number of clamp positions per pole	1
Inflammability class of insulation material according to with UL94	V0
Closing plate required	No
Type of electrical connection 1	Spring clamp connection
Type of electrical connection 2	Spring clamp connection
Transparent	No
Connectable conductor cross section solid-core	0.75-4 mm²
Connectable conductor cross section fine-strand with cable end sleeve	0.75-2.5 mm²
Connectable conductor cross section fine-strand without cable end sleeve	0.25-4 mm²
Connectable conductor cross section multi-wired	0.25-2.5 mm²
Material insulation body	Thermoplastic

1-conductor female connector Push-in CAGE CLAMP® 4 mm² Pin spacing 5.2 mm 1-pole Strain relief plate 4,00 mm² green-yellow
