832-1103/333-000 1-conductor female connector; lever; Push-in CAGE CLAMP®

Name: 832-1103/333-000 1-conductor female connector; lever; Push-in CAGE CLAMP®
Brand: WAGO
Price: 6.980 EUR
Availability: PreOrder

In stock: No Vendor stock: No Minimal order quantity: 15

Price (excl. VAT):

6,98 €

This price is valid until 24.12.25

Subtotal: 104,70 € MOQ: 15

EAN: 4055143936576

MPN: 832-1103/333-000

Package: 1

Box: 15

Estimate delivery time at our warehouse (approx.): 4-6 weeks

Technical Information

Item condition	New
Manufacture name	832-1103/333-000 1-conductor female connector; lever; Push-in CAGE CLAMP®
Brand	WAGO
Categories	Terminal Block Accessories
Country of origin	DE
Harmonized System Code	8536 6990 00
Rated voltage	1000 V
Rated current In	76 A
Explosion-tested version 'Ex e'	No

Packing details

Packing level 1	4055143936576
Packing level 2	4055143936576

Other Technical data

Mounting method	Other
Colour	Other
Width	10.16 mm
Height	45.7 mm
Depth	29.1 mm
Number of poles	3
Operating temperature	-60-120 °C
Number of clamp positions per pole	1
Inflammability class of insulation material according to with UL94	V0
Closing plate required	No
Type of electrical connection 1	Spring clamp connection
Type of electrical connection 2	Spring clamp connection
Transparent	No
Connectable conductor cross section solid-core	0.75-16 mm²
Connectable conductor cross section fine-strand with cable end sleeve	0.75-16 mm²
Connectable conductor cross section fine-strand without cable end sleeve	0.75-25 mm²
Connectable conductor cross section multi-wired	0.75-25 mm²
Material insulation body	Thermoplastic

Description

1-conductor female connector; lever; Push-in CAGE CLAMP®; 16 mm²; Pin spacing 10.16 mm; 3-pole; 100% protected against mismating; Strain relief plate; Silver-plated contacts; 16,00 mm²; light gray
