Tariff switch, 63A, 3 p, 50-63 A

Order only

Price (excl. VAT):

44,61 €

This price is valid until 24.12.25

EAN: 4015082668624

MPN: 266862

Package: 1

Box: 40

Estimate delivery time at our warehouse (approx.): 4-6 weeks

Technical Information

Item condition	New
Manufacture name	Tariff switch, 63A, 3 p, 50-63 A
Brand	EATON
Categories	Motor protection circuit-breakers
Country of origin	RS
Harmonized System Code	8536 5080 00
Rated permanent current Iu	0 A
Number of poles	3
Rated operating voltage	400 V
Overload release current setting	50-63 A
Degree of protection (IP)	IP20
Rated short-circuit breaking capacity lcu at 400 V, AC	0 kA
Adjustment range undelayed short-circuit release	50-63 A

Packing details

Packing level 1	4015082668624
Packing level 2	9007912329343

Other Technical data

Width	54 mm
Height	75 mm
Depth	80 mm
Rated operation power at AC-3, 400 V	0 kW
With integrated auxiliary switch	No
With integrated under voltage release	No
With thermal protection	Yes
Type of electrical connection of main circuit	Screw connection
Type of control element	Rocker lever
Switch off technique	Magnetic
Rated operation power at AC-3, 230 V	0 kW
Phase failure sensitive	No
Device construction	Complete device in housing

Description

Switching device for voluntary or tariff-based current limiting for consumer systems, design conforms to EN/IEC 60898-1, EN/IEC 60947, utility company-approved, easy for power customers to switch back on, set screw underneath sealable cover cap
