XT4V 160 BREAKING PART 3p F F
In stock: No
Vendor stock: Yes
Minimal order quantity: 1
Price (excl. VAT):
1 129,77 €
per pcs
EAN: 8056221003155
MPN: 1SDA100261R1
Package: 1
Estimate delivery time at our warehouse (approx.):
By request
Technical Information
| Item condition | New |
| Manufacture name | XT4V 160 BREAKING PART 3p F F |
| Brand | ABB |
| Categories |
Power Circuit Breakers
|
| Harmonized System Code | 8538 9099 00 |
| Rated permanent current Iu | 160 A |
| Number of poles | 3 |
| Rated voltage | 690 V |
| Degree of protection (IP) | IP20 |
| With switched-off indicator | No |
| Rated short-circuit breaking capacity lcu at 400 V, 50 Hz | 150 kA |
| Integrated earth fault protection | No |
| Device construction | Built-in device fixed built-in technique |
Packing details
| Packing level 1 | 8056221003155 |
Other Technical data
| Number of auxiliary contacts as normally open contact | 0 |
| Number of auxiliary contacts as normally closed contact | 0 |
| With integrated under voltage release | No |
| Number of auxiliary contacts as change-over contact | 0 |
| Position of connection for main current circuit | Front side |
| Motor drive integrated | No |
| Type of electrical connection of main circuit | Bolt connection |
| Type of control element | Toggle |
| Suitable for DIN rail (top hat rail) mounting | No |
| Motor drive optional | Yes |
| DIN rail (top hat rail) mounting optional | Yes |
| Complete device with protection unit | No |
Downloads
Others
Deep link REACH
Declaration RoHS
Declaration DOC CE (Declaration of conformity CE)
Product data sheet
Description
XT4H 250 Ekip Dip LIG In=250A 4p F F
