Wide-range switching power supply unit 12V DC

Order only Not Available

Estimate delivery time to our warehouse: By request

Technical Information

Item condition	New
Manufacture name	Wide-range switching power supply unit 12V DC
Brand	ELTAKO
Country of origin*	CN
* The actual country of origin may differ depending on the delivery batch. To confirm the specific country of origin, please contact your account manager.
Harmonized System Code	8504 3180 00
ETIM	EC002540
Width	18 mm
Height	58 mm
Depth	58 mm
Voltage type of supply voltage	AC
Power output	12 W
Rail mounting possible	Yes
Wall mounting possible	No
1st secondary output voltage	24 V
Rated supply voltage at AC 50 Hz	110-240 V
Max. output current 1	0.5 A

Packing details

Packing level 1	4010312901755, 4010312901755
Packing level 2	4010312901755
Packing level 3	4010312901755

Other Technical data

Built-in width	18 mm
Modular version	Yes
Suitable for safety functions	No
Width in number of modular spacings	1
Output voltage stabilized	Yes
Type of electric connection	Screw connection
Stabilized	Yes
Degree of protection (IP)	IP20
Direct mounting possible	No
Secondary voltage adjustable	No
Short-circuit-proof	Yes
Nominal value output voltage 1	24 V

Downloads

Deep link product page

Description

Wide-range switching power supply unit. Rated capacity 12W. Standby loss 0.2 watt only. Modular devices for DIN 60715 TH35 rail mounting. 1 module = 18mm wide, 58mm deep. At a load of more than 50% of the rated capacity and always if there are adjacent switching power supply units from 12W rated capacity and if there are dimmers a ventilation clearance of 1/2 module must be maintained with the spacers DS12 on both sides. Wide-range input voltage 88-264V AC (110V -20% up to 240V +10%). Efficiency 24V DC 86%. Stabilised output voltage ±1%, low residual ripple. Short-circuit proof. Overload protection and over-temperature switch-off by means of swichting off with automatic switching-on after fault clearance (autorecovery function).
