Wiring System interface with indicator of correct cable insertion, nom XW6T0016B
In stock: No
Vendor stock: No
Minimal order quantity: 1
Price (excl. VAT):
3,35 €
EAN: 4549734509305
MPN: XW6T-COM2.5X8RD
Package: 1
Estimate delivery time at our warehouse (approx.):
4-6 weeks
Technical Information
| Item condition | New |
| Manufacture name | Wiring System interface with indicator of correct cable insertion, nom XW6T0016B |
| Brand | Omron |
| Categories |
DIN Rail Terminal Blocks
|
| Country of origin | NL |
| Harmonized System Code | 8536 9010 00 |
| Mounting method | DIN rail (top hat rail) 35 mm |
| Rated voltage | 800 V |
| Type of electrical connection 1 | Spring clamp connection |
| Type of electrical connection 2 | Spring clamp connection |
| Number of levels | 1 |
| Number of clamp positions per level | 8 |
| Connectable conductor cross section solid-core | 0.14-4 mm² |
| Connectable conductor cross section fine-strand with cable end sleeve | 0.14-2.5 mm² |
| Connectable conductor cross section fine-strand without cable end sleeve | 0.14-2.5 mm² |
| Rated current In | 24 A |
Packing details
| Packing level 1 | 4549734509305, 4549734509305 |
Other Technical data
| Colour | Grey |
| Operating temperature | -40-55 °C |
| Inflammability class of insulation material according to with UL94 | V0 |
| Closing plate required | No |
| Internally connected stages | No |
| Material insulation body | Thermoplastic |
| Explosion-tested version 'Ex e' | No |
Downloads
Description
Wiring System interface with indicator of correct cable insertion, nominal cross section 2.5 mm², 8 pins, red short bar
