Wandboiler, SHZ 80 LCD, 80 l, 1 ton 6 kW, wit
Order only
EAN: 4017212312537
MPN: 231253
Package: 1
Price (excl. VAT)
1 178,87 €
per unit
MOQ: 1
EDT to our warehouse: 4-6 weeks
This price is valid until next price list or while stock lasts
Technical Information
| Item condition | New |
| Manufacture name | Wandboiler, SHZ 80 LCD, 80 l, 1 ton 6 kW, wit |
| Brand | STIEBEL ELTRON |
| Categories |
Boilers and heaters
|
| Country of origin* | DE |
| * The actual country of origin may differ depending on the delivery batch. To confirm the specific country of origin, please contact your account manager. | |
| Harmonized System Code | 8516 1080 00 |
| ETIM | EC011391 |
| Nominal power | 6 kW |
| Material boiler tank | Steel |
| Degree of protection (IP) | IP25 |
| Connection voltage | 230-400 V |
| Low-pressure model | Yes |
| Outer pipe diameter drainage connection | 21.5 mm |
| Design form | Hanging |
Packing details
| Packing level 1 | 4017212312537, 4017212312537 |
Other Technical data
| Width | 510 mm |
| Height | 1050 mm |
| Depth | 510 mm |
| With tap/mixer | No |
| Tank volume | 80 l |
| Energy efficiency class | B |
| With temperature limit | Yes |
| With thermometer | Yes |
| With temperature indication | Yes |
| Frequency | 50/60 Hz |
| Horizontal positioning | No |
| Water heating energy efficiency (Nwh) | 40 % |
| Capacity profile | M |
| Nominal diameter drainage connection | 1/2 inch (15) |
| Nominal diameter hot tap water | 1/2 inch (15) |
| Nominal diameter cold tap water | 1/2 inch (15) |
| Material casing | Steel |
| Tap capacity at 60 °C, continuous | 18 l/min |
| Heat-up time from 10 °C to 65 °C | 48 min |
| With cleaning opening | No |
| Protective anode | Yes |
| Wall set-up | Yes |
| Outer pipe diameter cold tap water | 21.5 mm |
| Outer pipe diameter hot tap water | 21.5 mm |
| With circulation connection | No |
| With pressure reducing valve | No |
| Cold tap water connection | External thread |
| Hot tap water connection | External thread |
| Circulation pipe connection | Internal thread |
| Connection, drainage connection | Other |
| Vertical positioning | Yes |
| Duo model | No |
| Three-phase model | Yes |
| With off-peak electricity circuit | Yes |
| Nominal diameter circulation pipe | Other |
| Suitable for boiling water | No |
| With watercooler | No |
| Plinth boiler | No |
Downloads
Product data sheet for energy label
Mounting instruction
Others
Deep link REACH
Dimensioned drawing
Product data sheet
Videos
Description
STIEBEL ELTRON Wandboiler SHZ 80 LCD, 80 l, 1 tot 6 kW, wit De drukvaste wandboilers voorzien meerdere tappunten van warm water. Naar keuze drukloos bij het voorzien van één tappunt. Tweespan-, eenspan- of boilerwerking zijn mogelijk. COMFORTKENMERKEN: tot op de graad nauwkeurige temperatuurinstelling door elektronische regeling. Verlicht lcd-display voor de weergave van de gewenste temperatuur, het beschikbare volume gemengd water, het energieverbruik, de status en de service-indicatie. ECO-functies voor energiebesparing. De snelverwarmingstoets kan via een externe, op afstand bediende knop worden geactiveerd. EFFICIËNTIE: instelbare ECO-modi, weergave van het energieverbruik en ECO Dynamic-functie. Lage energieverliezen en recyclebaar ontwerp. In nachtstroomwerking is naar keuze een achterwaartse besturing mogelijk. INSTALLATIE: instelbaar aansluitvermogen. Vervanging door alle gangbare wandboilers. Stevige grip tijdens het dragen dankzij grijpuitsparingen.
