WALL SOCKET 125A-4P 6H IND 415V
Order only
Not Available
Estimate delivery time to our warehouse: By request
Technical Information
| Item condition | New |
| Manufacture name | WALL SOCKET 125A-4P 6H IND 415V |
| Brand | EATON |
| ETIM | EC001321 |
| IEC-amperage | 125 A |
| Connection system | Screwed terminal |
| Contact material | CuZn |
| Degree of protection (IP) | IP66 |
| Voltage according to EN 60309-2 | 380-415 V (50+60 Hz) red |
Packing details
| Packing level 1 | 4250217406782 |
Other Technical data
| Model | Surface mounted (plaster) |
| RAL-number | 7.035 |
| Cable entry | Other |
| Number of poles | 4 |
| Insulated mounting | Yes |
| Material | Plastic |
| Type of fastening | External mounting |
| Surface treatment contacts | Galvanized |
| Military model | No |
| Clock hour position | 6 h |
| Identification colour | Red |
Description
Wall socket for industrial application, 125 A, 4-pole380-415 V, 6 h, 1 x M63 cable gland, 1 x M63 threaded plug
