EWK-G46/31 Wall-mounted enclosure EWK complete, IP31, 288 SU, protection class II, HxWxD=950x1050x230mm
In stock: No
Vendor stock: No
Minimal order quantity: 1
Price (excl. VAT):
665,89 €
EAN: 9010238008335
MPN: 193170
Package: 1
Estimate delivery time at our warehouse (approx.):
1-4 weeks
Technical Information
| Item condition | New |
| Manufacture name | EWK-G46/31 Wall-mounted enclosure EWK complete, IP31, 288 SU, protection class II, HxWxD=950x1050x230mm |
| Brand | EATON |
| Categories |
Small Distribution Boards
|
| Country of origin | CZ |
| Harmonized System Code | 8538 1000 00 |
| Mounting method | Surface mounted (plaster) |
| Housing material | Steel |
| Degree of protection (IP) | IP31 |
| Cover model | Closed |
| Signal passing door | No |
Packing details
| Packing level 1 | 9010238008335 |
Other Technical data
| Colour | White |
| Width | 1050 mm |
| Height | 950 mm |
| Depth | 225 mm |
| RAL-number | 9016 |
| With mounting plate | No |
| Built-in depth | 230 mm |
| Number of rows | 6 |
| Built-in height | 950 mm |
| Type of cover | Door |
| Built-in width | 1050 mm |
| EMC-version | Yes |
| Extension possible | Yes |
| Inner depth | 128 mm |
| DIN-rail | Yes |
| Width in number of modular spacings | 48 |
| Type of closure | Other |
| Transparent cover/door | No |
| With lock | No |
| Earthing terminal block | Yes |
| Neutral terminal block | Yes |
Description
EWK wall-mount enclosure including standard mounting units, 288 SU for modular DIN devices, Plastic protective shroud, Galvanized high-grade steel mounting rails, Compact enclosure dimensions, since the depth is only 230 mm, Rated operational current max. 160A, for direct mounting on the wall, IP31 degree of protection as per standard IEC/EN 62208, Protection class 2, isolation protection, Adjustable hinges for easily changing the door handing, very sturdy, door 2 wing, 1 clip-in, cable entry via F3A-2K flanges (not included) possible, including N-terminal: 4x (6x2.5-16mm² + 21x1.5-4mm²), including PE-terminal: 4x (6x2.5-16mm² + 21x1.5-4mm²), Colour: white , RAL 9016
