Wall and ceiling luminaire Solegra HCL Cover disc White around ETDD8 19W 2700lm Lambertian (L) IK06 3 SDCM

Round LED wall and ceiling luminaire with linear cylindrical design. The lateral surface of the diffuser can be custom-designed using an optional coloured profile frame (ZP). For ceiling and wall mounting.. Suspended mounting possible via optional accessories. Fixing the cover to the luminaire body is via simple-to-use bayonet catches with protection against twisting. With cylindrical diffuser made of translucent PMMA. With Lambertian light distribution. Glare evaluation according to UGR rating (EN 12464-1) < 22. When combined with the optional accessory profile frame + CDP panel (ZP..CDP...), the application as a ceiling luminaire is suitable for VDU workstations in accordance with EN 12464-1. With HCL equipment for controlling the light color by means of a separate control unit (DT8). Luminaire luminous flux 2700 lm, connected load 19 W, maximum luminous efficiency of luminaire 142 lm/W. Light colour variable (warm white - daylight white), correlated colour temperature (CCT) variable (2700 K - 6500 K), general colour rendering index (CRI) Ra > 80. Colour locus tolerance (initial MacAdam) ≤ 3 SDCM. Mean rated service life L80(tq 25 °C) = 50,000 h. The light source is replaceable according to the ecodesign requirements (VO (EU) 2019/2020). Luminaire body sheet steel. Surface coated white (RAL 9016). Diameter of diffuser Ø 400 mm, luminaire height 121 mm. Permissible ambient temperature (ta): -20 °C - +25 °C. Safety class (EN 61140): I, protection rating (DIN EN 60529): IP20, impact resistance level in accordance with IEC 62262: IK06, testing temperature of wire glow test in accordance with IEC 60695-2-11: 650 °C. Weight: 3,3 kg. With electronic control gear unit for switching, dimming and controlling the light colour using DALI Device Type 8-capable control unit. Control gear unit according to DALI-2 standard (EN 62386). The control gear unit is replaceable in accordance with the ecodesign requirements (VO (EU) 2019/2020). The luminaire can be equipped with the Monitoring Ready (MOR) functionality on request. The luminaire complies with the fundamental requirements of applicable EU regulations and product safety legislation and bears the CE symbol. Luminaire available for 10 years, spare parts (LED module, control gear unit, optical system) for 15 years from date of invoice, subject to reasonable modifications in the interests of progress.
