voltage transformer - 230..400 V - 2 x 115 V - 25 VA
In stock: No
Vendor stock: No
Minimal order quantity: 1
Price (excl. VAT):
64,28 €
EAN: 3389119401173
MPN: ABT7PDU002G
Package: 1
Pallet: 30
Estimate delivery time at our warehouse (approx.):
4-6 weeks
Technical Information
| Item condition | New |
| Manufacture name | voltage transformer - 230..400 V - 2 x 115 V - 25 VA |
| Brand | Schneider Electric |
| Categories |
Low Voltage Transformers
|
| Country of origin | CZ |
| Width | 87 mm |
| Height | 98 mm |
| Depth | 108 mm |
| Conductor material | Other |
| Degree of protection (IP) | Other |
| Primary voltage 1 | 230 V |
| Primary voltage 2 | 400 V |
| Built as safety transformer | No |
| Built as isolating transformer | No |
| Secondary voltage 1 | 115-230 V |
| Rated apparent power | 25 VA |
Packing details
| Packing level 1 | 3389119401173 |
| Packing level 2 | 3389119401173 |
Other Technical data
| Modular version | No |
| Suitable for mounting on PCB | No |
| Ring core | No |
| Built as energy saving transformer | No |
| Type of insulation material according to IEC 85 | A |
| Short-circuit-proof | No |
| Relative short circuit voltage | 0 % |
Downloads
ECOP (Environmental Code of Practice)
Technical manual
Declaration EPD (Environmental Product Declaration)
Declaration DOC CE (Declaration of conformity CE)
Mounting instruction
Description
This ABT7 transformer supplies alternating current to control circuits while isolating them from mains power. It has a rated input voltage of 230V to 400V AC, a rated output voltage of 115/230V AC thanks to its double secondary winding, and a rated power of 25VA. It offers an economic way to supply each consuming load individually, or by groups of loads, in applications such as mining, refining. It is ideal for systems accepting low voltage AC power, such as motor protection relays, contactors.
