voltage transformer - 230..400 V - 1 x 24 V - 1600 VA
In stock: No
Vendor stock: No
Minimal order quantity: 1
Price (excl. VAT):
560,04 €
EAN: 3389110598001
MPN: ABL6TS160B
Package: 1
Pallet: 4
Estimate delivery time at our warehouse (approx.):
4-6 weeks
Technical Information
| Item condition | New |
| Manufacture name | voltage transformer - 230..400 V - 1 x 24 V - 1600 VA |
| Brand | Schneider Electric |
| Categories |
Low Voltage Transformers
|
| Country of origin | CZ |
| Width | 174 mm |
| Height | 221 mm |
| Depth | 167 mm |
| Conductor material | Other |
| Degree of protection (IP) | IP20 |
| Primary voltage 1 | 230-400 V |
| Primary voltage 2 | 385-415 V |
| Built as safety transformer | Yes |
| Built as isolating transformer | Yes |
| Secondary voltage 1 | 24 V |
| Rated apparent power | 1600 VA |
Packing details
| Packing level 1 | 3389110598001 |
| Packing level 2 | 3389110598000 |
Other Technical data
| Modular version | No |
| Suitable for mounting on PCB | No |
| Ring core | No |
| Built as energy saving transformer | No |
| Type of insulation material according to IEC 85 | F |
| Short-circuit-proof | No |
| Relative short circuit voltage | 2.5 % |
Downloads
Description
This ABL6 transformer supplies alternating current to control circuits while isolating them from mains power. It has a rated input voltage of 230V to 400V AC, a rated output voltage of 24V AC and a rated power of 1.6kVA / 1600VA. It offers an economic way to supply each consuming load individually, or by groups of loads, in applications such as mining, refining. It is ideal for systems accepting low voltage AC power, such as motor protection relays, contactors.
