Ventilation gland, M16, 4-8mm, stainless steel, IP68

Order only Not Available
Estimate delivery time to our warehouse: By request

Technical Information

Item condition New
Manufacture name Ventilation gland, M16, 4-8mm, stainless steel, IP68
Brand Morek
ETIM EC000441
Model Straight
Thread length 6 mm
Material quality Stainless steel V2A
Thread type Metric
Material Metal
Suitable for cable diameter 4-8 mm
Degree of protection (IP) IP68
Nominal thread size metric/PG 16

Other Technical data

Halogen free Yes
Bend radius protection/trumpet flare No
With strain relief Yes
EMC-version No
Type of sealing Sealing ring
Operating temperature -20-100 °C
Explosion-tested version No
With locknut No
Separable screw gland Yes
Snapping in opening No
Wrench width 17 mm
