Heavy Duty Capacitor PowerLogic PFC Capacitor, 240 V, IP20, Electrical Parameters: 2.7 kvar 240 V 50 Hz

Order only

EAN: 3606485255606

MPN: BLRCH027A033B24

Box: 3

No price options are available.

Technical Information

Item condition	New
Manufacture name	VARPLUS CAN 240V 2.7 LEFT
Brand	Schneider Electric
Categories	Capacitors
Country of origin*	IN
* The actual country of origin may differ depending on the delivery batch. To confirm the specific country of origin, please contact your account manager.
ETIM	EC001516
Model	Other
Capacity	49.7 µF
Diameter	63 mm
With insert contacts	No
Nominal voltage	240-260 V
Capacity 2	0 µF

Packing details

Packing level 1

3606485255606

Other Technical data

Width	0 mm
Depth	0 mm
Length	245 mm

Description

VarPlus Can capacitor are a reliable and flexible solution for power factor correction in stringent operating conditions. These capacitors are particularly used for higher voltage disturbances or when a few non-linear loads are present. The rated current of the capacitors must be in increased in order to cope with the circulation of the harmonic current. This capacitor provides a rated output power of 2.7 kVar at 240V AC, 50 Hz. Fastening assured by a double Faston terminal. This component meet the standards IEC 60831-1 and IEC 60831-2. The case product weight is 0.7 kg.
