VALUE Flex® 1500 -G3-830-05
Order only
Price (excl. VAT):
100,57 €
Split box: 10,00 €
EAN: 4052899526075
MPN: 4052899526075
Package: 1
Box: 10
Pallet: 1000
Estimate delivery time at our warehouse (approx.):
4-6 weeks
Technical Information
| Item condition | New |
| Manufacture name | VALUE Flex® 1500 -G3-830-05 |
| Brand | OSRAM |
| Categories |
Light ribbon-/hose/-strip
|
| Country of origin* | CN |
| * The actual country of origin may differ depending on the delivery batch. To confirm the specific country of origin, please contact your account manager. | |
| Width | 8 mm |
| Beam angle | 120 ° |
| Colour rendering index CRI | 80-89 |
| Length | 5000 mm |
| Height/depth | 1.5 mm |
| Lamp type | LED not exchangeable |
| Degree of protection (IP) | IP20 |
| Lamp power per meter | 11.5 W |
| Lamp voltage | 24 V |
| Colour temperature | 3000 K |
| Luminous flux per meter | 1520 lm |
Packing details
| Packing level 1 | 4052899526075 |
| Packing level 2 | 4052899526082 |
| Packing level 3 | 4052899526075 |
Other Technical data
| Mounting method | Surface mounting |
| Model | Strip |
| Conductor cross section | 0.519 mm² |
| Connection type | Other |
| Voltage type | DC |
| Self-adhesive | Yes |
| Number of poles | 2 |
| With protective cover | No |
| Lowest bending radius | 50 mm |
| Length of particular segments | 100 mm |
| With connection set | Yes |
| With end piece | Yes |
| Number of nodes per meter | 70 |
| Max. system power | 57.5 W |
| Colour of light | White |
| IFTTT support available | No |
| Rated life time L70/B50 at 25 °C | 50000 h |
| Degree of protection (NEMA) | 1 |
| Lamp power per foot | 3.5 W |
| Number of nodes per foot | 21 |
| Energy efficiency class of the built-in lamp | A++, A+, A (LED) |
| Compatible with Apple HomeKit | No |
| Compatible with Google Assistant | No |
| Compatible with Amazon Alexa | No |
| Luminous flux adjustable | Continuously variable |
| Beam angle adjustable | No |
Downloads
Description
Product family benefits: Energy saving low-power flexible LED strip. Pre-wired LED strip, simple and quick plug-and-play installation. Good light output due to homogeneous LED distance and high color consistency. Easy mounting on many smooth surfaces thanks to self-adhesive tape at the back. Easy installation with optional track system. Easy to cut and reconnect to the reliable SLIMCONNECT system. Product family features: Available with light color: Warm White, Cool White. Luminous flux: up to 1600 lm/m. High color consistency: 4 SDCM. Self-cooling. Beam angle per module: 120°. Dimmable with suitable OPTOTRONIC® control gears. Type of protection: IP20. Areas of application: Hospitality. Signage. Architecture lighting. Cove lighting. General illumination. Wall integration. Display cabinet lighting. Equipment / Accessories: SLIMCONNECT system FLEX IP54 connector. Optional Track system.
Alternative EAN
4058075236226
