NZM2/3-XU24AC-PI Undervoltage release for NZM2/3, 24AC, Push-in terminals
Order only
Price (excl. VAT):
57,91 €
EAN: 4015081877454
MPN: 189750
Package: 1
Estimate delivery time at our warehouse (approx.):
4-6 weeks
Technical Information
| Item condition | New |
| Manufacture name | NZM2/3-XU24AC-PI Undervoltage release for NZM2/3, 24AC, Push-in terminals |
| Brand | EATON |
| Categories |
Trip & Release Units
|
| Country of origin | RO |
| Harmonized System Code | 8538 9099 00 |
| Type of electric connection | Screw connection |
| Rated control supply voltage at AC 50 Hz | 24 V |
| Rated control supply voltage at AC 60 Hz | 24 V |
| Rated control supply voltage at DC | 0 V |
| Voltage type for actuating | AC |
Packing details
| Packing level 1 | 4015081877454 |
Other Technical data
| Delayed | No |
| Suitable for off-load switch | Yes |
| Suitable for overload relay | No |
| Suitable for motor safety switch | Yes |
| Suitable for power circuit breaker | No |
| Number of contacts as normally closed contact | 0 |
| Number of contacts as normally open contact | 0 |
| Number of contacts as change-over contact | 0 |
Description
Optional accessories for the circuit-breaker series NZM offers a comprehensive portfolio of application options for use world wide. The mounting is always flexible and easy thanks to the modular function groups. Notes: Undervoltage releases with push-in terminals. Non-delayed disconnection of circuit-breaker NZM when control voltage drops below 35 - 70 % Us. For use with emergency switching off devices in conjunction with emergency switching off buttom. When the undervoltage release is de-energized, accidental contact with the main contacts of the circuit-breaker dureing attempts to switch on is reliably prevented . Undervoltage release modules cannot be installed simultaneously with early-make contact NZM…-XHIV, shunt release NZM…-XA… or relais modules NZM...-X2A...
