NZM1-XUHIV20LK208-240AC Undervoltage release, 208-240VAC +2early N/O
Order only
Price (excl. VAT):
85,24 €
EAN: 4015082844042
MPN: 284404
Package: 1
Estimate delivery time at our warehouse (approx.):
1-4 weeks
Technical Information
| Item condition | New |
| Manufacture name | NZM1-XUHIV20LK208-240AC Undervoltage release, 208-240VAC +2early N/O |
| Brand | EATON |
| Categories |
Trip & Release Units
|
| Country of origin | RO |
| Harmonized System Code | 8538 9099 00 |
| Type of electric connection | Screw connection |
| Rated control supply voltage at AC 50 Hz | 208-240 V |
| Rated control supply voltage at AC 60 Hz | 208-240 V |
| Rated control supply voltage at DC | 0 V |
| Voltage type for actuating | AC |
Packing details
| Packing level 1 | 4015082844042 |
Other Technical data
| Delayed | No |
| Suitable for off-load switch | Yes |
| Suitable for overload relay | No |
| Suitable for motor safety switch | No |
| Suitable for power circuit breaker | Yes |
| Number of contacts as normally closed contact | 0 |
| Number of contacts as normally open contact | 2 |
| Number of contacts as change-over contact | 0 |
Description
Optional accessories for the circuit-breaker series NZM offers a comprehensive portfolio of application options for use world wide. The mounting is always flexible and easy thanks to the modular function groups. Notes: for interlocking and load-shedding circuits, as well as for early-make of the undervoltage release in main-switch applications. For use with Emergency-Stop devices in conjunction with emergency-stop button. when the shunt release is energized, accidental contact with the main contacts of the switch during attempts to switch on is safely prevented . Early make of auxiliary contacts on switching on and off (manual operation): approx. 20ms. Cannot be used in conjunction with NZM...-XR.. remote operator. Undervoltage releases cannot be installed simultaneously with NZM..-XHIV.. early-make auxiliary contact or NZM..-XA.. shunt release. Can be used for: NZM1(-4), N(N/O)1(-4)
