Under Undervoltage release, 18VDC, +2N/O early
Order only
Price (excl. VAT):
106,38 €
EAN: 4015081683345
MPN: 171800
Package: 1
Estimate delivery time at our warehouse (approx.):
4-6 weeks
Technical Information
| Item condition | New |
| Manufacture name | Under Undervoltage release, 18VDC, +2N/O early |
| Brand | EATON |
| Categories |
Trip & Release Units
|
| Country of origin | RO |
| Harmonized System Code | 8538 9099 00 |
| Type of electric connection | Screw connection |
| Rated control supply voltage at AC 50 Hz | 0 V |
| Rated control supply voltage at AC 60 Hz | 0 V |
| Rated control supply voltage at DC | 18 V |
| Voltage type for actuating | AC |
Packing details
| Packing level 1 | 4015081683345 |
Other Technical data
| Delayed | No |
| Suitable for off-load switch | Yes |
| Suitable for overload relay | No |
| Suitable for motor safety switch | No |
| Suitable for power circuit breaker | No |
| Number of contacts as normally closed contact | 0 |
| Number of contacts as normally open contact | 2 |
| Number of contacts as change-over contact | 0 |
Description
Optional accessories for the circuit-breaker series NZM offers a comprehensive portfolio of application options for use world wide. The mounting is always flexible and easy thanks to the modular function groups. Notes: non-delayed disconnection of NZM circuit-breaker or N switch-disconnector when the control voltage sinks below 35-70% US. For use with Emergency-Stop devices in conjunction with emergency-stop button. when the undervoltage release is de-energized, accidental contact with the main contacts of the switch during attempts to switch on is safely prevented . Undervoltage releases cannot be installed simultaneously with NZM..-XHIV.. early-make auxiliary contact or NZM..-XA.. shunt release. Can be used for: NZM1(-4), N(N/O)1(-4)
