XV-102-A0-35TQRB-1E4 Touch display for easyE4, 24 V DC, 3.5z, TFTcolor, ethernet
In stock: No
Vendor stock: Yes
Minimal order quantity: 1
Price (excl. VAT):
326,92 €
EAN: 7640130099500
MPN: 198513
Package: 1
Estimate delivery time at our warehouse (approx.):
4-6 weeks
Technical Information
| Item condition | New |
| Manufacture name | XV-102-A0-35TQRB-1E4 Touch display for easyE4, 24 V DC, 3.5z, TFTcolor, ethernet |
| Brand | EATON |
| Categories |
HMI Panels & Operator Interfaces
|
| Country of origin | DE |
| Harmonized System Code | 8537 1091 00 |
| Operating temperature | 0-50 °C |
| Voltage type of supply voltage | DC |
| Degree of protection (IP), front side | IP65 |
| Supply voltage AC 50 Hz | 0 V |
| Supply voltage AC 60 Hz | 0 V |
| Supply voltage DC | 20.4-28.8 V |
| Degree of protection (NEMA), front side | 4X |
Packing details
| Packing level 1 | 7640130099500 |
Other Technical data
| Built-in depth | 25 mm |
| Suitable for safety functions | No |
| Screen diagonal | 3.5 inch |
| Supporting protocol for LON | No |
| Number of HW-interfaces industrial Ethernet | 1 |
| Number of HW-interfaces RS-232 | 0 |
| Number of HW-interfaces RS-422 | 0 |
| Number of HW-interfaces RS-485 | 0 |
| Number of HW-interfaces serial TTY | 0 |
| Number of HW-interfaces USB | 1 |
| Number of HW-interfaces parallel | 0 |
| Number of HW-interfaces other | 0 |
| Supporting protocol for TCP/IP | Yes |
| Supporting protocol for ASI | No |
| Supporting protocol for PROFIBUS | No |
| Supporting protocol for CAN | No |
| Supporting protocol for INTERBUS | No |
| Supporting protocol for KNX | No |
| Supporting protocol for Modbus | Yes |
| Supporting protocol for Data-Highway | No |
| Supporting protocol for DeviceNet | No |
| Supporting protocol for SUCONET | No |
| Supporting protocol for other bus systems | Yes |
| With colour display | Yes |
| Number of colours of the display | 65536 |
| Number of pixels, horizontal | 320 |
| Number of pixels, vertical | 240 |
| Number of function buttons, programmable | 0 |
| With numeric keyboard | Yes |
| With alpha numeric keyboard | Yes |
| Useful project memory/user memory | 64000 kByte |
| With message indication | Yes |
| With message system (incl. buffer and confirmation) | Yes |
| Process value representation (output) possible | Yes |
| Process default value (input) possible | Yes |
| With recipes | Yes |
| Number of password levels | 200 |
| With printer output | Yes |
| Number of online languages | 100 |
| Additional software components, loadable | Yes |
| With SW interfaces | Yes |
| Width of the front | 136 mm |
| Height of the front | 100 mm |
| Rail mounting possible | No |
| Supporting protocol for SERCOS | No |
| Supporting protocol for INTERBUS-Safety | No |
| Number of interfaces PROFINET | 0 |
| Number of HW-interfaces Wireless | 0 |
| Wall mounting/direct mounting | No |
| Radio standard Bluetooth | No |
| Radio standard Wi-Fi 802.11 | No |
| IO link master | No |
| Supporting protocol for AS-Interface Safety at Work | No |
| Supporting protocol for DeviceNet Safety | No |
| Supporting protocol for EtherNet/IP | Yes |
| Supporting protocol for Foundation Fieldbus | No |
| Supporting protocol for PROFINET CBA | No |
| Supporting protocol for PROFINET IO | No |
| Supporting protocol for PROFIsafe | No |
| Supporting protocol for SafetyBUS p | No |
| Type of display | TFT |
| Number of grey-scales/blue-scales of display | 0 |
| Radio standard GPRS | No |
| Radio standard GSM | No |
| Radio standard UMTS | No |
| Number of buttons with LED | 0 |
| Number of system buttons | 1 |
| Touch technology | Resistive touch |
Description
XV-102 touch display for easyE4, 24 VDC, 3.5 inches, TFT color, Ethernet
