TOLEDO FLAT square, 11 W, 730 lm, 830, white, on/off Recessed downligh
Order only
Not Available
Estimate delivery time to our warehouse: By request
Technical Information
| Item condition | New |
| Manufacture name | TOLEDO FLAT square, 11 W, 730 lm, 830, white, on/off Recessed downligh |
| Brand | RZB |
| Country of origin* | DE |
| * The actual country of origin may differ depending on the delivery batch. To confirm the specific country of origin, please contact your account manager. | |
| Harmonized System Code | 9405 1190 00 |
| ETIM | EC001957 |
| Width | 172 mm |
| Length | 172 mm |
| Height/depth | 3 mm |
| Lamp type | LED not exchangeable |
| Impact strength | IK03 |
| Nominal voltage | 200-240 V |
| Degree of protection (IP) | IP54 |
| Colour temperature | 3000 K |
| Max. system power | 11 W |
| Rated luminous flux according to IEC 62722-2-1 | 730 lm |
Packing details
| Packing level 1 | 4051859178385, 4051859178385 |
Other Technical data
| Mounting method | Built-in |
| Protection class | I |
| Function | Escape route lighting |
| Lamp holder | None |
| Conductor cross section | 2.5 mm² |
| Connection type | Other |
| Colour housing | White |
| Voltage type | AC |
| Power supply system | Peripheral (individual battery) |
| Type of control gear | LED operating device current-controlled |
| With remote control | No |
| Built-in width | 156 mm |
| Suitable for labelling type | Other |
| Number of poles | 4 |
| Housing material | Aluminium |
| Number of lighting heads | 1 |
| Built-in length | 156 mm |
| Material cover | Plastic, opal |
| Battery quality | NiMH |
| With light source | Yes |
| Luminaire with limited surface temperature, sign "D“ according to EN 60598-2-24 | No |
| Suitable for number of lamps | 1 |
| With remote switch connection | No |
| Monitoring equipment | Automatic self test |
| Nominal current | 46-55 |
| Constant light output (CLO) | No |
| With pictogram | No |
| Type of wiring | Ending |
| Luminous flux in standby mode | 340 lm |
| Degree of protection (NEMA) | Other |
| Rated ambient temperature according to IEC62722-2-1 | 5-35 °C |
| Light distributor | Other |
| Nominal operation time | 3 h |
| Max. number of luminaires per miniature circuit breaker C16 | 143 |
| Max. number of luminaires per miniature circuit breaker B16 | 85 |
| Exchangeable control gear | Yes |
| Built-in height/depth | 110 mm |
| Power factor | 0.5 |
Downloads
Description
Square recessed downlight. For escape route illumination. Housing: die-cast aluminium, powder-coated. Lightguide and diffuser made of non-yellowing plastic (PMMA). Diffuser opal matt plastic. Ceiling installation with spring system. Including separate LED converter with connecting cable 250 mm. Self-contained system with automatic self-test. External driver with simple plug-in locking system.
