Three-pole earthing and short-circuiting cable 95mm² with crimped cabl

Name: Three-pole earthing and short-circuiting cable 95mm² with crimped cabl
Brand: Dehn
Price: 1704.770 EUR
Availability: PreOrder

Order only

Price (excl. VAT):

1 704,77 €

This price is valid until 31.12.25

EAN: 4013364165496

MPN: VE9HQHJ

Package: 1

Estimate delivery time at our warehouse (approx.): 2 weeks

Technical Information

Item condition	New
Manufacture name	Three-pole earthing and short-circuiting cable 95mm² with crimped cabl
Brand	Dehn
Categories	Electrical Safety Equipment
Country of origin	DE
Harmonized System Code	8535 9000 00
Model	Cable
Number of poles	3
Max. short circuit current	26.5 kA
Wire cross section, phase-side	95 mm²
Wire cross section, earth-side	95 mm²

Packing details

Packing level 1

4013364165496, 4013364165496

Other Technical data

Material	Copper
Length phaseline a	600 mm
Length phaseline b	600 mm
Length phaseline c	600 mm
Length earth line	1800 mm
Connecting part, phase-side	Universal clamp 20/25 mm
Connecting part, earth-side	Universal clamp 20/25 mm

Downloads

Product data sheet Deep link REACH

Description

Three-pole earthing and short-circuiting device according to EN/IEC 61230 (DIN VDE 0683-100), cable cross-section: 95 mm² / 95 mm², maximum short-circuit current / duration: 26.5 kA / 0.5 s - 2.5; length A=B=C= 600 mm, length D = 1800 mm; phase cables equipped with 3x universal clamp Ø20/25 mm, T-pin shaft (Part No. 773 234) and earth cable equipped with 1x universal clamp Ø20/25 mm with handle (Part No. 774 234).
